iTECH FDR-C5G-IT High Quality SMT Vibratory Feeder for Pick and Place Machine
iTECH FDR-C5G-IT High Quality SMT Vibratory Feeder for Pick and Place Machine
Factory
NO.1,Shanha Road Nanming Mountain Street, Liandu District, Li Shui Shi
323000 Zhejiang
China
Factory Wenzhou
6/F, International Chamber of Commerce Building, Renhui Road, Ouhai District Wenzhou
325000 Zhejiang
China
EXCLUSIVELY FOR PICK AND PLACE MACHINE PPM-A320, PPM-A320V AND PPM-A320VB
The Vibratory Feeder with 5 Channels
R & D by our company Huaqi Zhengbang.
Model: PPM-A320VB
Mounting Numbers: 2PCS
Mounting Precision: 0.025mm
Mounting Angle: 0~360°
Mounting Speed: 5500pcs/hour
Suction Nozzle Type: Juki Series Nozzle
Applicable Element:
RC (0402, 0603, 0805, 1206 etc)
LED Lamp Beads (0603, 0805, 3014, 5050 etc)
Chip (SOT, SOP, QFN, BGA etc)
SMD Height: ≤5.5mm (Customize ≤11mm)
PCB Minimal Size: 10×10mm
PCB Maximum Size: 320×450mm
PCB Thickness: ≤2mm
Components Reel Type: 8mm, 12mm, 16mm, 24mm, 32mm
Front IC Location: 10pcs
Back IC Tray: 1pc
Vibration Stick Feeder: iTECH Customized Feeder (Optional)
X/Y Axis Moving Range: 430×530mm
Z Axis Moving Range: 10mm
Z Axis Rotation Angle: 0~360°
Visual Camera: CCD High-definition Camera
Numbers of Visual: Parts Camera×3, PCB Camera×1
Recognition Capability: MAX. 22×22mm
PC System: Microsoft WIN7
Operational Software: R & D
Compatible File Format: CSV. TXT. Format
Program Method: Support Online and Offline Ways
Air Pressure: 0.4Mpa
Vacuity Degree: -66kpa
Power: 230W
Voltage: AC220V±10% 50Hz
Net Weight: 85kgs
Gross Weight: 114kgs
Machine body Size: L990×W730×H375mm
1#Materials Feeder Outline Size: L235×W700×H245mm
2#Materials Feeder Outline Size: L235×W485×H245mm
Package Dimension: 1340*840*590mm
